PORTS (IN-OUT):

3/4"

PORTS (EXH):

1-1/4"

PORT THREAD:

NPT

ACTUATION:

Manual

CV (IN-OUT):

13.12

CV (EXH):

8.98

FUNCTION:

3/2

FLOW MEDIA:

Filtered Air

INLET PRESSURE RANGE:

0 to 300 psig (0 to 21 bar)

MEDIA TEMPERATURE RANGE:

40 to 175 F (4 to 80 C)

AMBIENT TEMPERATURE RANGE:

40 to 175 F (4 to 80 C)

WEIGHT:

2.5 lbs (1.13 kg)
